Pervious Paver Roll - NDS EZ 4X24 - 4' x 24'
Pervious Pavers for Grass Driveways and Parking Lots


Questions? Call (800) 524-4161


Price: $474.32


Free Shipping
Availability:: In stock
Product Code: EZ4X24-P
Qty:

Description


Pervious Paver Roll - 4' x 24



For use on Grass Parking Lots, Driveways and Roads

The NDS EZ Roll Pervious Grass Pavers offer a turf brace and load transferring paving to directly place directly on a specific compacted road base. It's designed to shift vehicle weight directly to a supportive base course to stop soil compaction. The honeycomb cells offer protection from vehicle loads as well as lateral containment to prevent soil compaction from stopping healthy root growth. The system is also porous which will allow for fast absorption of stormwater.

The pervious paver provides a compressive strength of 53,683 lbs when empty and 400,000 lbs when loaded with native topsoil. This level of compressive strength allows for the EZ roll to be used in a wide variety of applications from grass parking lots to driveways and access roads.

Pervious Pavers in a roll for installation on driveways and parking areas

  • Model: EZ4X24
  • Size: 4' x 24'
  • Square Footage Per Roll: 96
  • Color: Black
  • Material Thickness: 1"
  • Made in the USA

  • Ultra-Strong Hexagonal Design:Fused hexagonal design provides superior strength and long term durability when compared to pavers which rely on linked circles or squares for strength.


  • Free Shipping

  • Contact us for volume pricing on orders of 25+ rolls.

  • Would You Like a Written Quote?
  • Looking for a Larger Roll?
    4' x 150' rolls are also available.

  • Looking for a paver that can be filled with gravel? Consider the TT-24 or GP4X150

Pervious Pavers in a parking lot setting

Constructed for Strength

Pervious grass pavers are a great alternative for a continuous, traditional paving approach. By protecting a root area and stopping soil compaction, the pavers allow healthy grass to thrive in areas that traditionally have impenetrable hardscaping in place.

Some of the recommended applications include service roads, jogging tracks, golf cart and bike paths, residential driveways, parking lots, roadway shoulders, overflow parking lots, and access roads for emergency vehicles. Other excellent locations include truck maintenance areas, equipment yards, and construction entrance soil stabilization.

The EZ Roll Pervious Grass Paver is a reliable choice to control erosion on slopes and in swales.

Installation

The 4 to 6-inch aggregate base must be placed directly below the pavers. The grassroots will grow into the gravel and anchor firmly. If the gravel base is not installed, you will get a cookie-cutter effect preventing the pavers from sinking into the soil.


The Design

The Pervious Grass Paver has rolls that are pre-assembled making it easier to roll out, decreasing installation time, and being more productive.

The product is tested for compressive strength at 53,683 lbs, bare product which means Pervious Paver Roll does not depend on the fill material for load carrying.

The rows are connected and secured with a side-to-side design and end-to-end clips that prevent the paver's mat from moving and separating caused by lateral and horizontal pressure. The powerful locking clips will prevent paver displacement or grid failure that could result from traffic load movement or a change in the ground conditions.


Pervious paver strength rating

The Material

100% recycled HDPE plastic 50% post-consumer and 50% pre-consumer, HDPE is very rugged and flexible making it ideal for outside exposure and longevity. NDS uses UV inhibitors in the polymer to stop breakdowns in its strength.

Paver Details

The top surface of the hexagonal cell walls is smooth and minus any notches or grooves. The bottom surface of the paver mat offers more than 80% open area for increased absorbency.

Pervious Pavers Roll have exceptional chemical resistance and are totally immobile.


• Compressive Strength (Empty Cells). 53,683 lbs.

• Compressive Strength (Native Soil-filled Pavers): 400,000 lbs.

The EZ Roll Pavers feature an easy-to-install top-down locking mechanism. This locking mechanism will allow pavers to be installed very quickly and easily.

The EZ Roll Grass Pavers from NDS offers the latest and most advanced design of its kind on the market. With many years of experience in the landscaping industry, NDS has created a product with the latest and most sought-after features.

Empty cells have a compressive strength of 51,683 lbs.

The product ships in large rolls for easy rollout and easy to connect.

CASE STUDY DLR Savvis Center Emergency Access Lane In San Jose, CA

Permeable Pavers were chosen for the environmentally susceptible grass emergency access lane at the DLR Savvis Data Center in San Jose, CA.

EZ Roll Permeable Grass Paver was chosen over the original competitor's specified plastic grid because of its unique ability to support the heavyweight of emergency vehicles while still creating a beautifully pleasant green area to enhance the landscape. Its expansive open surface of EZ Roll offered an enhanced root area which was one of the reasons they chose NDS EZ Roll over the competition. EZ Roll Permeable Pavers are an excellent green alternative over concrete and asphalt due to its sustainable grass growth.

EZ Roll offers the strength and durability of pavement with the beauty and absorbency of natural grass. This product is the perfect environmentally sustainable solution. This product curtails stormwater runoff by allowing moisture to naturally filter into the soil. The contractor, Jensen Corporation, was very pleased with the product stating that this kind of project would normally take 2 to 3 days to complete but this project was completed in a single day thanks to how easy it rolled out and how simple it was to install. The empty compressive strength of EZ Roll was unmatched by their competitors' products. The overall experience added even further to the fast installation time by allowing Jensen to drive over the empty product and fully-loaded dump trucks and other heavy vehicles to deliver the base materials exactly where they were needed.

WORLD'S STRONGEST
ROLLED PERMEABLE PAVER.

How does the NDS EZ-Roll measure up against it's competitors? View the detailed 3rd party testing report.

Get Answers to Frequently Asked Questions

Or give us a call at (800) 524-4161

Need to Reinforce Tire Tracks in a Lawn?

The EZ4X24 & EZ4X150 grass paver rolls "un-hinge" down the middle of the 4' wide piece. This leaves you with (2) 2' wide strips which are perfect for reinforcing tire tracks in a lawn. No cutting required!


Features


NDS Paver Shipping Time:

NDS orders typically ship same day if the order is placed before 12:00 noon EST. Transit times displayed in the map are listed in business days, are approximate and are specific to NDS products only. Transit days can increase up to a total of 5 business days if low stock is experienced at your closest warehouse (this is vary rare). The day that the order is shipped is not counted as a transit day.

The transit times displayed on the map are for standard ground shipping.

Looking for a Product to Protect Your Existing Grass?

Grass protection mesh can be installed over your existing grass providing light / medium duty reinforcement.

Engineered for Strength

EZ Roll Pervious Grass Pavers are a sustainable alternative to traditional paving methods. By protecting the root zone and preventing soil compaction, the pavers allow healthy grass to thrive in areas that would traditionally have impervious hardscaping installed.

Recommended Applications: Golf cart paths, service roads, jogging tracks, bike paths, residential driveways, parking lots, overflow parking lots, roadways shoulders, emergency vehicle access roads, truck maintenance and equipment yards, construction entrance soil stabilization.

In addition to these load applications, EZ Roll Pervious Grass Pavers are also an effective solution for erosion control on slopes and in swales.

NDS Permeable Paver Brochure

Download a printable version of the NDS permeable paver brochure

A sandy loam fill allows water to filter through the base while supporting healthy root growth.

EZ Roll Grass Paver at Dry Creek Elementary allowed the school to use this grassy area as an overflow parking lot.


Flexible plastic paver mats are pre-assembled into rolls for easy installation on the job site.


Installation

  • 4" - 6" aggregate base must be installed directly below the pavers (see illustration below). The grass roots will grow into the aggregate (gravel) and anchor firmly. If an aggregate base isn't installed, a "cookie cutter" effect will take place and the pavers can sink into the soil.
  • If an aggregate base isn't practical for the project, consider the TT-24 Grass Pavers which feature a tapered bottom and can be placed directly over soil without sinking.

  • EZ4X24 Installation Diagram (click to enlarge):

Installation Guide & Technical Information

Download a printable version of the EZ-Roll Installation Guide

Environmental Benefits

  • Permeable surfaces eliminate or reduce stormwater runoff
  • Stormwater filters naturally through subsurface, reducing pollutants
  • Urban Heat Island (UHI) effect is mitigated as grass does not absorb as much heat energy as traditional hardscapes
  • Pavers are made of 100% recycled plastic

Competitive Benefits

  • Empty cells have a compressive strength of 57,890 psf
  • Product ships in large rolls for easy roll-out
  • Grass root zone is reinforced and protected by gridwork of hexagonal cells

  • Reduces demands put on landscape drainage system

  • Less expensive to maintain over time than traditional hardscaping

  • More pleasing aesthetically than traditional hardscaping

Case Studies

Case study: Emergency access lane - Denton Sr Center - Denton, TX
Download PDF

Case study: Emergency access lane - DLR Savvis Center - San - Jose, CA
Download PDF

Case study: Emergency grass access lane - Trump Taj Mahal Casino Resort - Atlantic City, NJ
Download PDF

Case study: Fire lane - Dell Customer Care Center - Oklahoma City, TX
Download PDF

Case study: Headstone stabilization - LA National Cemetery - Los Angeles, CA
Download PDF

Case study: Overflow parking - LeMay America's Car Museum - Tacoma, WA
Download PDF

Case study: Overflow parking lot - Keller High School - Tulsa, OK
Download PDF

Case study: Right-of-way - Walden Ave - Depew, NY
Download PDF

Additional Technical Information

EZ Roll Grass Pavers Guide Specification 4 13 15
Download Word DOC

Grass Paver EZ Roll Flexible Porous Paving Sec 32 12 43
Download Word DOC

Grass Paver EZ Roll Porous Pavement Sec 02795
Download Word DOC

Bio Retention Pavers for Detention
Download PDF DWG

EZ Roll Grass Pavers Edging, Type 1
Download PDF DWG

EZ Roll Grass Pavers Edging, Type 2
Download PDF DWG

EZ Roll Grass Pavers Edging, Type 3 Reflector
Download PDF DWG

EZ Roll Grass Pavers Fire Heavy Load
Download PDF DWG

EZ Roll Grass Pavers Liberty Mountain Overflow Parking Light Load
Download PDF DWG

EZ Roll Grass Pavers Light Load
Download PDF DWG

EZ Roll Grass Pavers Medium Load
Download PDF DWG

EZ Roll Grass Pavers Staking
Download PDF DWG

Infiltration Paver for Infiltration
Download PDF DWG

EZ Roll Grass Pavers
Download PDF
